The Part Number is 3SK74.

Crss Mosfet Capacitance

The function of this semiconductor is MOSFET.

Manufacturers : NEC Electronics

See the preview image and the PDF file for more information.


Mosfet Gate Capacitance

Description : N-Channel Silicon dual-gate MOSFET

Features

1. Suitable for use as RF amplifier & Mixer in VHF TV Tuner
2. Low Crss : 0.03pF Typ.
3. High PG : 22dB Typ.
4. Low NF : 2.0dB Typ.

1 page

Absoulte Maximum ratings

1. Drain to Source Voltage : Vdsx = 20 V
2. Gate1 to Source Voltage : Vg1s = ± 10 V
3. Gate2 to Source Voltage : Vg2s = ± 10 V
4. Drain Current : Id = 25 mA
5. Total Power Dissipation : Pt – 200 mW

Mosfet Output Capacitance

3SK74 Datasheet

Crss Capacitance
